March 10, 2010, 13:25
Larry Buchanmainspring for 18 size Ball Hamilton 19 jewel
Could anybody tell me what replacement mainspring I need for a Hamilton Ball 18 size, 19 jewel, movement. I would like to use an alloy type spring.
Larry
March 10, 2010, 22:35
Samie L. SmithLarry COULD BE ONE OF 2 DIFFERENT SPRING i think these were based on the hamilton 944 19 jewel movement(if i am wrong someone correct me) if so it,s probaly a motor barrel watch..The e&j swigart book has the number 14 spring listed for the 944 -width is 3.18 mm- length 25-1/4 inches long thickennes is .018 ..this one had what looks like a hook on one side of the spring That hooks into the bottom of the barrel but no tab in the mainspring barrel cover ,this is more than likley the one you need.
The other one listed is a number 232 with the same lenth-width-strenght as the other but has a tab on both sides of the spring..One tab goes into the bottom of the mainspring barrel and the other tab into the barrel cover.
When the mainspring barrel is removed from the watch it will be easy too tell which one it uses./
hope this helps
SAMIE
March 11, 2010, 11:34
Larry BuchanSammie thank you for the information, I think it is the No 14 that you mentioned
Larry
March 11, 2010, 22:50
David AbbeLarry, I sent you an e-mail about some 1890-1901 Orioginal Rand/Mcnally Canadian and North-Northwestern US Railroad maps I have. Did you recieve that? I sent it to your e-mail address in this site.
March 12, 2010, 11:15
Larry BuchanHello Dave:
Yes I received your e-mail okay.
Larry
